Acting type: Double acting, Tube I.D.: φ25, 32 (mm), Proof pressure: 1.5 MPa, Available speed range: 50~3000 mm/sec.
- The diameter of the port orifice has been enlarged to support high speed operation. max speed: 3000mm/sec.
- Longer cushion rod to absorb more exercise energy and reduce external cushioning settings.
- The cylinder with relief valve provides better cushioning performance than the general purpose cylinder with needle valve.
- The relief valve body can rotate 360 degrees freely, which is convenient for adjustment and use.
- Magnetic as standard.
| Acting type | Double acting |
|---|---|
| Tube I.D. (mm) | 25, 32 |
| Port size | Rc1/3, Rc3/8 |
| Medium | Air |
| Max. operating perssure | 1 MPa |
| Min. operating perssure | 0.05 MPa |
| Proof pressure | 1.5 MPa |
| Lubrication | Not required |
| Ambient temperature | －5℃~＋60℃ (No freezing) |
| Available speed range | 50~3000 mm/sec |
| Cushion | Air cushion |
| Max energy absorption | 12, 21 J |
| Standard Stroke (*1,2,3) | 250~1000 mm |
| Max. stroke | 1500 mm |
| Effective cushioning stroke | 80 mm |
| Sensor switch | RCM |
| Sensor switch band | BMG25, BMG32 |
| Remark | *1. Minimum stroke unit 1mm. *2. Outside the guaranteed range when the stroke exceeds standard stroke, Please reconfirm the dimension with our sales department when the stroke over our standard. *3. This product has a large absorption energy and a longer effective buffer range. Therefore, when the stroke below 250mm is used at high speed, the cushioning performance may not meet the catalog standard. |
