Tube I.D. φ3/4”~2 1/2”(inch). Max. operating pressure: 1 MPa, Min. operating pressure: 0.05 MPa, Proof pressure: 1.5 MPa.
- Many mounting options available.
- Interchangeable with other manufacturers.
| Acting type | Double acting |
|---|---|
| Tube I.D. (inch) | 3/4″, 1″, 1 1/4″, 1 1/2″, 2″, 2 1/2″ |
| Port size Rc(PT) | NPT1/8, NPT1/4 |
| Medium | Air |
| Max operating pressure | 1 MPa |
| Min operating pressure | 0.05 MPa |
| Proof pressure | 1.5 MPa |
| Ambient temperature | －5~＋60°C (No freezing) |
| Lubrication | Not require |
| Available speed range | 50~500 mm/sec |
| Max. allowable kinetic energy | Cushion pad 0.07~0.85 J Cushion air 0.09~1.23 J |
| Cushion | With rubber cushion pad |
| Sensor switch | RCM |
| Sensor switch holder | BMG20~BMG63 |
