Tube I.D. φ 6, 8 (mm). High precision combination of cylinder and linear rail. Flush fitting sensor groove. Magnetic as standard.
- High precision combination of cylinder and linear rail.
- Flush fitting sensor groove.
- Magnetic as standard.
| Acting type | Double acting |
|---|---|
| Tube I.D. (mm) | 6, 8 |
| Port size | M5×0.8 |
| Medium | Air |
| Operating pressure range | 0.15~0.7 MPa |
| Proof pressure | 1 MPa |
| Ambient temperature | －5~＋60℃ (No freezing) |
| Lubricator | Not required |
| Available speed range | 50~500 mm/sec |
| Cushion | Rubber bumpper (Standard) ; Shock absorber (Option) |
| Sensor switch | RDC, RQC |
