Assembling style: MCQVS, Wiring method: 2 wire, AISI 316 stainless steel Fits the chemical, food and pharmaceutical environment. The switch holds up to corrosive environments, high temperature and shock.
- AISI 316 stainless steel Fits the chemical, food and pharmaceutical environment.
- The switch holds up to corrosive environments, high temperature and shock.
| Wiring method | 2 wire |
|---|---|
| Switching logic | SPST N.O. |
| Switch type | Reed switch |
| Operating voltage | 5~240V DC/AC |
| Switching current | 100mA max. |
| Switching rating | 10W max. (※1) |
| Voltage drop | 3.5V max. |
| Indicator | Red LED |
| Housing switch material | Sensor switch: AISI 316, LED box: ABS |
| Cable | Teflon: φ4, L=4000mm, PVC: φ3, L=1000mm |
| Temperature range | －10℃~＋140℃ (Sensor switch only) |
| Enclosure classification | IEC 529 IP67 |
| Weight | 91g (2m cable) |
| Connect diagram | ※1: Warning: Never exceed rating (watt=voltage×amperage). Permanent damage to sensor will occur. |
