Assembling style: MERE, Supply voltage: 12~24VDC± 10%,Pulsation(P-P)10% less, Current consumption: <10mA, Load current: 100mA
| Supply voltage | 12~24VDC± 10%,Pulsation(P-P)10% less |
|---|---|
| Current consumption | <10mA |
| Load current | 100mA |
| No load current | <0.01ma no-load=”” –0=”” 01ma–=””> |
| Detection distance | 0~2 mm |
| Min. detection object | 1×8×8 (Iron) |
| Ripple | <1.5VDC(Load 100mA,wire 2M) |
| Repeat accuracy | <1% Detection distance |
| Frequency | 600 HZ |
| Power reverse connection protection | Yes |
| Output short circuit protection | Yes |
| Switching output | RJF-N: NPN, N.O. RJF-P: PNP, N.O. |
| Ambient operating temperature | -25 ~ 70°C |
| Temperature drift | <10% Detection distance |
| Enclosure rating | IP67 |
| Voltage withstand | 100VAC 50~60HZ 1min |
| Insulation resistance | >20MΩ |
| Connection type | ø3×2M/3M, 3-wires |
| Housing material | ABS/PBT |
| Accessories | M2.5 screw ×1, M2.5 nut ×1 |
| Weight | Approx. 24g (2M), 36g (3M) |
