Detection distance: 5 mm, Repeat accuracy: 0.03 mm以下, Operating voltage: 5~24 VDC, Current consumption: ≤8mA, Degree of protection: IP50, Case material: PC, Wight: 25 g
| Detection distance | 5 mm (slot width) |
|---|---|
| Standard detection object | Opaque objects larger than 0.8×1.2 mm |
| Repeat accuracy | ≤ 0.03 mm |
| Contact type | NPN, PNP |
| Switch mode | Switchable between L.on (Light ON mode) and D.on (Dark ON mode) |
| Indicator light | When an object is detected, the light turns off; when no object is present, the light remains on |
| Response frequency | 3KHz |
| Light source | Infrared LED |
| Operating voltage | 5~24 VDC |
| Residual voltage | 1V or below (at a load current of 100mA) |
| Current consumption | ≤8mA |
| Protection circuit | Surge protection, reverse polarity protection |
| Ambient light intensity | Illuminance on the receiving surface: Below 1000 lux (incandescent lamp) |
| Ambient temperature | Operating: –25~+55°C, Storage: –30~+80°C (No freezing) |
| Ambient humidity | Operating: 5~85%RH, Storage: 5~95%RH (No condensation) |
| Dielectric strength | AC, 1000V for 1 minute, between all power connection terminals and the outer casing |
| Vibration resistance | 10~55 Hz, amplitude 1.5mm, 2 hours each in the X, Y, and Z directions |
| Insulation resistance | Between all power connection terminals and the outer casing, more than 20MΩ (based on DC 250V) |
| Degree of protection | IP50 |
| Case material | PC |
| Wiring method | 24M – 4 core cable |
| Wight | 25 g |
